Sensorius 1/2.7" Progressive Scan CMOS
Min.apšvietimas Color: 0.009 Lux @ (F1.6, AGC ON), 0 Lux with IR
Užrakto laikas 1/3 s to 1/100,000 s
Lėtas užraktas Yes
WDR 120 dB
Diena/naktis ICR Cut
Kampo valdymas Pan: 0° to 360°, tilt: 0° to90°, rotate: 0° to 360°
Objektyvas 2.8 mm, horizontal FOV: 97°, vertical FOV: 52°, diagonal FOV: 114° 4 mm, horizontal FOV: 79°, vertical FOV: 42°, diagonal FOV: 93°
Diafragma F1.6
Montavimas M12
Fiksuota diafragma Yes
IR atstumas Up to 30 m
Bangos ilgis 850 nm
Vaizdinis pavojaus signalas Yes
Maks.raiška 2560 × 1440
Pagr. srautas 50Hz: 25 fps (2560 × 1440, 1920 × 1080, 1280 × 720) 60Hz: 30 fps (2560 × 1440, 1920 × 1080, 1280 × 720)
Antrinis srautas 50Hz: 25 fps (640 × 360) 60Hz: 30 fps (640 × 360)
Vaizdo suspaudimas Main stream/Sub-stream: H.265/H.264
Vaizdo bitų greitis 32 Kbps to 8Mbps
H.264 tipas BaseLine Profile/Main Profile/High Profile
H.265 tipas Main Profile
Srauto tipas Main stream and sub-stream
ROI 1 fixed region for main stream
Aplinkos triukšmo slopinimas Yes
Garso ėminių dažnis 8 kHz/16 kHz
Garso suspaudimas G.711/G.722.1/G.726/MP2L2/PCM
Garso bitų greitis 64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-160Kbps(MP2L2)
Transliacija Up to 6 channels
API ISAPI, SDK
Protokolai TCP/IP, ICMP, HTTP, FTP, DHCP, DNS, DDNS, RTP, RTSP,R TCP, NTP, UPnP, SMTP, IGMP, QoS, IPv6, UDP, Bonjour, SSL/TLS
User/Host Up to 32 users 3 levels: Administrator, Operator and User
Apsauga Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for ONVIF, RTP/RTSP OVER HTTPS, Control Timeout Settings, Security Audit Log, TLS 1.2
Tinklo saugykla NAS (NFS, SMB/CIFS)
Kliento programinė įranga Wired network: Hik-Connect, iVMS-4200 Wi-Fi: iVMS-4200
Naršyklė Plug-in required live view: IE8+, Chrome41.0-44, Firefox30.0-51, Safari8.0-11; Plug-in free live view: Chrome 45.0+, Firefox 52.0+
Diena/naktis jungiklis Day/Night/Auto/Schedule
Vaizdo gerinimas BLC, HLC, 3D DNR
Vaizdo nustatymai Saturation, brightness, contrast, sharpness, AGC, and white balance are adjustable by client software or web browser
Garsas 1 built-in microphone, 1 built-in speaker
Vidinė atmintis Built-in micro SD/SDHC/SDXC slot, up to 256 GB
Perkrovimas Yes
Ryšio sąsaja 1 RJ45 10M/100M self-adaptive Ethernet port
Pagrindinis įvykis Motion detection, flashing alarm light output, audible alarm output, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error)
Susiejimo metodai Upload to NAS/memory card, notify surveillance center, trigger record, trigger capture, strobe light, audible warning
Atnaujinimas internetu Yes
Programinės įrangos versija V5.5.132
Pagrindinės funkcijos One-key reset, anti-flicker, heartbeat, mirror, password protection, watermark, IP address filter, flash log, pixel counter
Programinis perkrovimas Yes
Saugyklos darbo sąlygos -30 °C to 60 °C (-22 °F to 140 °F)
Paleidimo ir darbinės sąlygos -30 °C to 60 °C (-22 °F to 140 °F)
Maitnimas 12 VDC±25%, reverse polarity protection
Suvartojimas 12 VDC, 0.67 A, max.8.0 W
Galios sąsaja Ø5.5 mm coaxial power plug
Medžiaga Front cover: metal, back cover: plastic
Kameros matmenys 175.6× 73.0 × 89.1 mm (6.91" × 2.87" × 3.51")
Pakuotės matmenys 260 × 125 × 125 mm (10.24" × 4.92" × 4.92")
Kameros svoris 450 g (0.99 lb.)
Svoris su pakuote 770 g (1.70 lb.)
EMC FCC ID (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 6, 2016); KC (KN 32: 2015, KN 35: 2015)
RF FCC ID (FCC Part 15.247(BT or 2.4G)); IC ID (RSS-247(BT or 2.4G)); CE-RED (EN 301489-1 V2.1.1(BT or 2.4G); EN 301489-17 V3.1.1(BT or 2.4G); EN 300328 V2.1.1(BT or 2.4G); EN 62311:2008(BT or 2.4G)); WPC (EN 301 489-1 V2.1.1(BT or 2.4G); EN 301 489-17 V3.1.1(BT or 2.4G); EN 300 328 V2.1.1(BT or 2.4G); EN 62311:2008(BT or 2.4G); EN 55032:2015; EN 61000-3-2:2014; EN 61000-3-3:2013; EN 50130-4:2011 +A1:2014); KC (KN 32:2015; KN 35: 2015; KN 301489-1; KN 301489-17); ICASA (EN 301 489-1 V2.1.1(BT or 2.4G); EN 301 489-17 V3.1.1(BT or 2.4G); EN 300 328 V2.1.1(BT or 2.4G); EN 62311:2008(BT or 2.4G); EN 55032:2015; EN 61000-3-2:2014; EN 61000-3-3:2013; EN 50130-4:2011 +A1:2014; EN 60950-1:2005 + Am 1:2009 + Am 2:2013)
Saugumas UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013); BIS (IS 13252(Part 1):2010+A1:2013+A2:2015); LOA (IEC/EN 60950-1)
Aplinka CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006) Reach Regulation (EC) No 1907/2006
Apsauga Ingress protection: IP66 (IEC 60529-2013)
Šifravimas 64/128-bit WEP, WPA-EAP/WPA2-EAP, WPA-PSK/WPA4-PSK
Wi-Fiprotokolas IEEE802.11b, 802.11g, 802.11n
Dažnio diapazonas 2.4 GHz - 2.4835 GHz
Kanalų dažnio juosta 20/40 MHz
Moduliavimas 802.11b: CCK, QPSK, BPSK 802.11g/n: OFDM
Bevielio tinklo aprėptis Up to 120 m (The performance varies based on actual environment.)
